The TE Connectivity RT2 General Purpose Power PCB Relay is designed for diverse power applications, offering 2-pole 8A relays with contact arrangements of 2 Form C (CO) and 2 Form A (NO). It provides reinforced insulation with 5kV/10mm coil-contact and is approved according to IEC 60335-1. The relay operates within a temperature range of -40°C to +85°C and supports coil voltages from 5V DC to 110V DC and 24V AC to 230V AC. It has a coil resistance range of 62Ω to 28,800Ω and a coil power range of 400mW to 420mW. The maximum contact switching voltage is 400V AC, with a maximum breaking capacity of 2000VA. The contact material is AgNi 90/10, with operate/reset times of max. 10/5ms and bounce times of max. 4/9ms. The relay is suitable for applications such as boiler controls, timers, garage door controls, POS automation, and interface modules.
