Solis S2-WL-ST Wi-Fi/LAN Data Logger, 4-Pin

SKU: S2-WL-ST(4PIN)-Serialized
(0)No Reviews yet

by Solis

Solis S2-WL-ST Wi-Fi/LAN Data Logger, 4-Pin

SKU: S2-WL-ST(4PIN)-Serialized

(0)No Reviews yet
The Solis S2-WL-ST (4-Pin) is a plug-in Wi-Fi/LAN data logger for all Solis inverters except the S6 hybrid. It sends inverter data to SolisCloud and monitors up to 10 daisy-chained inverters from one logger.
$184.62

In Stock

Product Description

Solis S2-WL-ST Wi-Fi/LAN Data Logger, 4-Pin

The S2-WL-ST connects to a local router by Wi-Fi or Ethernet and sends inverter data to SolisCloud for remote monitoring and control. It stores up to 30 days of data for one inverter if the connection drops and backfills the gap when the network returns.

  • 4-Pin connector; for all Solis inverters except the S6 hybrid
  • Wi-Fi 802.11b/g/n (2.4 GHz only) and 10/100 Mbps Ethernet
  • Up to 10 inverters per logger (inverters daisy-chained with RS485)
  • Bluetooth for local setup and debugging; one-button configuration
  • Alarm notifications by text and email; Modbus TCP support
  • NEMA 4X; plug-and-play install
  • 2-year warranty on accessories (Solis North America)
ConnectionExternal 4-pin port, twist lock
Data interval5 minutes
Power consumption2 W typical
Operating temperature-22 to 149 F
Dimensions (L x W x H)5.7 x 2 x 1.6 in
Weight0.22 lb
CertificationCE, FCC

For the Solis S6 hybrid inverter, use the USB version: S2-WL-ST(USB).
